buildspec.yml for building the container image and pushing to the Elastic Container Registrybuildspec.yml in the root of the source code repository.version: 0.2
phases:
pre_build:
commands:
- echo Logging in to Amazon ECR...
- aws --version
- aws ecr get-login-password | docker login --username AWS --password-stdin $REPOSITORY_URI
- COMMIT_HASH=$(echo $CODEBUILD_RESOLVED_SOURCE_VERSION | cut -c 1-7)
- IMAGE_TAG=${COMMIT_HASH:=latest}
build:
commands:
- echo Docker build and tagging started on `date`
- docker build -t $REPOSITORY_URI:latest -t $REPOSITORY_URI:$IMAGE_TAG .
- echo Docker build and tagging completed on `date`
post_build:
commands:
- echo Build completed on `date`
- echo Pushing the docker images...
- docker push $REPOSITORY_URI:latest
- docker push $REPOSITORY_URI:$IMAGE_TAG
- echo Update the REPOSITORY_URI:IMAGE_TAG in task definition...
- echo Container image to be used $REPOSITORY_URI:$IMAGE_TAG
- sed -i 's@REPOSITORY_URI@'$REPOSITORY_URI'@g' taskdef.json
- sed -i 's@IMAGE_TAG@'$IMAGE_TAG'@g' taskdef.json
- echo update the REGION in task definition...
- sed -i 's@AWS_REGION@'$AWS_REGION'@g' taskdef.json
- echo update the roles in task definition...
- sed -i 's@TASK_EXECUTION_ARN@'$TASK_EXECUTION_ARN'@g' taskdef.json
artifacts:
files:
- "appspec.yaml"
- "taskdef.json"
The artifacts appspec.yaml and taskdef.json are used by the CodeDeploy.
For Amazon ECS compute platform applications, the AppSpec file is used by CodeDeploy to determine your Amazon ECS task definition file. TASK_DEFINITION placeholder will be replaced by the CodeDeploy automatically after registering the new taskdef.json.
version: 0.0
Resources:
- TargetService:
Type: AWS::ECS::Service
Properties:
TaskDefinition: "<TASK_DEFINITION>"
LoadBalancerInfo:
ContainerName: "nginx-sample"
ContainerPort: 80
taskdef.json is the ECS task definition. New version is created by CodeDeploy for each deployment. We are replacing the below placeholders in the CodeBuild phase of the CodePipeline
{
"containerDefinitions": [
{
"name": "nginx-sample",
"image": "REPOSITORY_URI:IMAGE_TAG",
"portMappings": [
{
"containerPort": 80,
"protocol": "tcp"
}
],
"essential": true,
"dockerLabels": {
"name": "nginx-sample"
},
"logConfiguration": {
"logDriver": "awslogs",
"options": {
"awslogs-group": "/ecs/nginx-sample",
"awslogs-region": "AWS_REGION",
"awslogs-stream-prefix": "nginx-sample"
}
}
}
],
"taskRoleArn": "TASK_EXECUTION_ARN",
"executionRoleArn": "TASK_EXECUTION_ARN",
"family": "nginx-sample",
"networkMode": "awsvpc",
"requiresCompatibilities": [
"FARGATE"
],
"cpu": "256",
"memory": "1024"
}
appspec.yaml and taskdef.json are being replaced in the buildspec.ymlENVIRONMENT variables in the CDK stackWe have completed the review for the blue/green deployment using CodeDeploy and ECS. Let’s cleanup the resources.
